TT-AK24IPG-14 Air Knight – IPG Air Purification System 24V 14″ 3-7.5T – E:Mail: sales@walkair.us to confirm availability or for volume discounts
The Air Knight IPG 24V 14″ Air Purification System is an in duct indoor air quality solution designed for 3–7.5 ton residential and light commercial HVAC systems. It combines bipolar ionization and UV technology to help reduce airborne particles, odors, and contaminants as air moves through the system.
Ideal for contractors seeking an add on IAQ solution that installs easily into existing ductwork without impacting airflow or system performance.
Key Features & Benefits
• UL 2998 validated – no ozone emissions, making it suitable for occupied spaces
• Bipolar ionization (IPG technology) using carbon fiber ionization brushes to increase ion output
• PX5 UV technology supplements particulate reduction within the air stream
• Designed to work with existing HVAC filtration, improving overall system effectiveness
• High airflow housing supports modern high SEER and light commercial systems
• 24V operation for simple integration with standard HVAC control systems
| Attributes | |
|---|---|
| Additive Technologies | Carbon fiber ionization; PX5 photo ionic oxidation |
| Amps | 1.2 |
| Approvals | UL Listed; UL Recognized |
| Brand | Air Knight |
| CFM | 3000 |
| Country of Origin | USA |
| Cubic Measurement | 0.7415 |
| Cycle/Hertz | 50/60 Hz |
| Dimensional Weight | 4 |
| Electrical Rating | 24V |
| Input Voltage | 24 VAC |
| Lamp Dimensions | 11.5625″ |
| Lamp Life | 2 Years |
| Lamp Spectrum | 185 nanometers |
| Lamp Type | Ultraviolet |
| Maximum Temperature | 185°F (85°C) |
| Mounting Type | Duct |
| Operating Temperature Range | <150°F (65.5°C) |
| Phase | Single |
| Power Supply | 24 VAC |
| Prop 65 | YES |
| Reduces Bacteria | YES |
| Reduces Mold | YES |
| Reduces Odors | YES |
| Reduces Viruses | YES |
| Removes Bacteria | NO |
| Removes Mold | NO |
| Removes Odors | NO |
| Removes Viruses | NO |
| UL2998 Standard | NO |
| UL867 Standard | NO |
| UOM | EA |
| UPC | 747454001343 |
| Voltage | 24 VAC |
