Description
Factory Authorized Parts – ZR57K3E-TF5-930 Scroll Compressor – E:Mail: sales@walkair.us to confirm availability or for volume discounts
Benefits of Copeland scroll compressors:
– Only three moving parts–fewer moving parts means less maintenance needed. By contrast, other reciprocating compressors can have up to nine moving parts in each cylinder.
– No complex internal valves–the simplified design resists liquid refrigerant slugging, debris and failure,
– Higher efficiency–Copeland was one of the first companies to create partial load operation across its compressor line. Their scroll compressors tend to be more efficient across its entire operating range.
– Lower vibration levels–this means not just less noise, but also less wear and tear on components.
| Attributes | |
|---|---|
| Amps | 11.1-14.5 |
| Approvals | UL Recognized |
| BTU Output | 57,000 |
| Brand | Copeland |
| Compressor Housing | Hermetic |
| Compressor Type | Scroll |
| Condensing Temperature | 130°F (54.44°C) |
| Country of Origin | USA |
| Cubic Measurement | 2.3238 |
| Cycle/Hertz | 50/60 Hz |
| Discharge Connection Size OD | 1/2″ |
| Discharge Connection Type | Stub |
| Displacement | 4.71 (in^3/Rev) |
| Evaporating Temperature | 45°F (7.22°C) |
| Liquid Temperature | 115°F (46.11°C) |
| Locked Rotor Amps (LRA) | 123 |
| Mass Flow (lbs/hr) | 860 lbs./hr.; 880 lbs./hr. |
| Mounting Dimensions | 7.5″ x 7.5″ x 17.99″ |
| OPT Code | ZR57K3E-TF5-930 |
| Oil Charge Initial (oz.) | 66 |
| Oil Type | Polyolester (POE) |
| Phase | Three |
| Prop 65 | YES |
| Protection | Yes |
| Rated Load Amps (RLA) | 19.3, 17.3 |
| Refrigerant | R-22 ; R-407C |
| Return Gas Temperature | 65°F (18.33°C) |
| Sound Level (dBA) | 74-79 |
| Suction Line Fitting Type | Stub |
| Suction Line Size (OD) | 7/8″ |
| UPC | See Optical |
| Voltage | 200/220, 200/230 VAC |
