Description
Factory Authorized Parts – HD60FK659 Belt Drive Blower Motor 5 HP 3Ph – E:Mail: sales@walkair.us to confirm availability or for volume discounts
Factory Authorized Parts™ – HD60FK659 Motor 5HP 3PH
Factory Authorized Parts are designed to meet exact Carrier® Corporation specifications ensuring optimum system performance, proven reliability, easy installation and maintenance, and safe system operation.
| Attributes | |
|---|---|
| Amps | 6.3-12.6 |
| Approvals | CSA Listed |
| Bearing Type | Ball |
| Brand | Factory Authorized Parts |
| Country of Origin | MEX |
| Cubic Measurement | 1.8594 |
| Cycle/Hertz | 60 Hz |
| Dimensional Weight | 24 |
| Duty | (S1) Continuous Running Duty |
| GTIN | 00822529602950 |
| Motor Enclosure | Open Drip Proof (ODP) |
| Motor HP | 5 |
| Motor Type | PSC (Permanent Split Capacitor) |
| Mounting Type | Rigid |
| NEMA Frame | 184T |
| Number of Speeds | Variable |
| Phase | Three |
| Prop 65 | NO |
| RPM | 1,755 |
| Rotation | Clockwise (CW) |
| UOM | EA |
| UPC | 822529602950 |
| Voltage | 230/460 VAC |
