Factory Authorized Parts – P040-16251 Danfoss Scroll Compressor, 162,600 Btu, 200/230-3-60 V, 45.7 RLA, R22 – E:Mail: sales@walkair.us to confirm availability or for volume discounts
P040-16251 is a Danfoss branded Scroll Compressor that is Three phase with a voltage of 208/230 VAC. The compressor is designed to work in units that are compatible with a BTU Output of 162600 and use R-22 refrigerant.
Please note, this is a special order, non-stock item and will be shipped direct from the vendor. Non-stock and Special Order items cannot be cancelled once processed, and are non-returnable. Customer is responsible for freight charges. These items may have an extended lead time. Use chat if you need to confirm lead time before ordering. By purchasing this product, you agree to these terms.
| Attributes | |
|---|---|
| Amps | 45.7 |
| BTU Output | 162,600 |
| Brand | Danfoss |
| Compressor Housing | Hermetic |
| Compressor Type | Scroll |
| Condensing Temperature | 130°F (54.44°C) |
| Country of Origin | USA |
| Cubic Measurement | 10.5 |
| Cycle/Hertz | 60 Hz |
| Dimensional Weight | 83 |
| Discharge Connection Size OD | 7/8″ |
| Discharge Connection Type | Sweat or Braze |
| Displacement | 1606 (cu.ft/Hr) |
| Evaporating Temperature | 45°F (7.22°C) |
| GTIN | 00662442750082 |
| Locked Rotor Amps (LRA) | 265 |
| Mounting Dimensions | 8.7″ x 8.7″ |
| Oil Charge Initial (oz.) | 107 |
| Oil Type | Mineral (MO) |
| Phase | Three |
| Prop 65 | NO |
| Protection | Yes |
| Rated Load Amps (RLA) | 45.7 |
| Refrigerant | R-22 |
| Sound Level (dBA) | 84 |
| Suction Line Fitting Type | Sweat or Braze |
| Suction Line Size (OD) | 1 3/8″ |
| UOM | EA |
| UPC | 662442750082 |
| Voltage | 200/230 VAC |
